AT080TN03 V.1

AT080TN03 V.1
AT080TN03 V.1
AT080TN03 V.1
AT080TN03 V.1 thumb AT080TN03 V.1 thumb AT080TN03 V.1 thumb
Waitohu
Innolux
Rahi
8.0
Taupānga
DPF
Whakatau
800×480
Te tito
LCM
Tirohanga
250
CR
300:1
Nga Tae
262K
Whakamuri
WLED
Atanga
TTL
In Stock
1916
Whakatakotoranga

Nama Wahi AT080TN03 V.1
WaitohuInnolux
Rahi8.0
TaupāngaDPF
Whakatau800×480
Te titoLCM
Tirohanga250
CR300:1
Nga Tae262K
WhakamuriWLED
AtangaTTL
panel brandINNOLUX
panel modelAT080TN03 V.1
panel type a-Si TFT-LCD , LCM
panel size8.0 inch
resolution800(RGB)×480 , WVGA
display modeTN, Normally White, Transmissive
active area176.64×99.36 mm
outline192.8×116.9 mm
surfaceAntiglare
brightness250 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colors262K (6-bit)
response time15/20 (Typ.)(Tr/Td)
viewing angle65/65/45/65 (Typ.)(CR≥10)(L/R/U/D)
lamp type3S9PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6-bit), 60 pins
input voltage3.3/10.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
applicationDPF
Tauira Whanau
AT080TN01 Innolux 8.0 800×480
AT080TN03 V.1 Innolux 8.0 800×480
AT080TN03 V.2 Innolux 8.0 800×480
AT080TN03 V.7 Innolux 8.0 800×480
AT080TN42 Innolux 8.0 800×600
AT080TN42 V.1 Innolux 8.0 800×600
AT080TN43 Innolux 8.0 800×600
AT080TN52 Innolux 8.0 800×600
AT080TN52 V.1 Innolux 8.0 800×600
AT080TN64 Innolux 8.0 800×480
