| Nama Wahi | EJ080NA-05B |
| Waitohu | Innolux |
| Rahi | 8.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CHIMEI INNOLUX |
| panel model | EJ080NA-05B |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141×5.9 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| input voltage | 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| L5F30614T65 | SANYO | 8.0 | 800×480 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| TM080SV-22L03 | SANYO | 8.0 | 800×600 |
| A104SN03 V0 | AUO | 10.4 | 800×600 |
| DLC0700EZG-1 | Other | 7.0 | 800×480 |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD100IFW1-A04 | HannStar | 10.1 | 1024×600 |
| HSD100IXN1-A00 | HannStar | 10.0 | 1024×768 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| LTE700WQ-F05 | Samsung | 7.0 | 480×234 |
| TR-LM7WR3PS | Panasonic | 7.0 | 480×234 |
