| Nama Wahi | EJ080NA-04A |
| Waitohu | Innolux |
| Rahi | 8.0 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | INNOLUX |
| panel model | EJ080NA-04A |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162.048×121.536 mm |
| outline | 183×141×3.7 mm |
| surface | Hard coating |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 6/14 (Typ.)(Tr/Td) |
| viewing angle | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| input voltage | 3.3/11.5/22/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| application | PAD |
