| Nama Wahi | LD089WX1-SL03 |
| Waitohu | LG Display |
| Rahi | 8.9 |
| Taupānga | PAD |
| Whakatau | 1280×768 |
| Te tito | LCM |
| Tirohanga | 370 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | LG Display |
| panel model | LD089WX1-SL03 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.9 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | S-IPS, Normally Black, Transmissive |
| active area | 193.92×116.352 mm |
| outline | 207×130.4×3.2 mm |
| surface | Glare (Haze 0%) |
| brightness | 370 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S4PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
