| Nama Wahi | LD089WU1-SM01 |
| Waitohu | LG Display |
| Rahi | 8.9 |
| Taupānga | PAD |
| Whakatau | 1920×1200 |
| Te tito | LCM |
| Tirohanga | 360 |
| CR | 800:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | LG Display |
| panel model | LD089WU1-SM01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.9 inch |
| resolution | 1920(RGB)×1200 , WUXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 191.52×119.7 mm |
| outline | 203.4×135.85×5.25 mm |
| surface | Hard coating |
| brightness | 360 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S5PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
