| Nama Wahi | CLAA070WP03 |
| Waitohu | CPT |
| Rahi | 7.0 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | CPT |
| panel model | CLAA070WP03 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 94.2×150.72 mm |
| outline | 104.32×161.67×4.05 mm |
| surface | Hard coating (3H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K (6-bit), CIE193160% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 31 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
