| Nama Wahi | CLAA098EP01XG |
| Waitohu | CPT |
| Rahi | 9.8 |
| Taupānga | |
| Whakatau | 1280×960 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | CPT |
| panel model | CLAA098EP01XG |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.8 inch |
| resolution | 1280(RGB)×960 , Quad-VGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 199.68×149.76 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit) + SPI |
