| Nama Wahi | CLAA090LC41CW |
| Waitohu | CPT |
| Rahi | 9.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | CPT |
| panel model | CLAA090LC41CW |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 198×112.08 mm |
| outline | 210.7×126.8×6 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193170% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/11.3/18.0/-6.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| application | CNS |
| AA090AA01 | Mitsubishi | 9.0 | 960×540 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| CLAA098EP01XG | CPT | 9.8 | 1280×960 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
| AT062TN12 | Innolux | 6.2 | |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA090NA06CW | CPT | 9.0 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| L5F30705T10 | Epson | 5.0 | 400×240 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| PM070WU1 | E Ink | 7.0 | 800×480 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM060RDH01 | Tianma | 6.0 | 800×480 |
