| Nama Wahi | NL8048BC24-12 |
| Waitohu | NLT |
| Rahi | 9.0 |
| Taupānga | IA |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 900:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | NEC |
| panel model | NL8048BC24-12 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 196.8×118.08 mm |
| outline | 220.5×136.5×8.7 mm |
| surface | Clear, Hard coating (3H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193160% |
| response time | 3/15 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3 stringsWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| LQ090Y3DG01 | SHARP | 9.0 | 800×480 |
| LQ090Y3DG01A | SHARP | 9.0 | 800×480 |
| LTA090B230F | TOSHIBA | 9.0 | 536×328 |
| NL8048AC19-13 | NLT | 7.0 | 800×480 |
| NL8048BC19-02 | NLT | 7.0 | 800×480 |
| NL8048BC19-02C | NLT | 7.0 | 800×480 |
| NL8048BC24-09D | NLT | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| NL8048BC24-14NH | NLT | 9.0 | 800×480 |
| EL160.80.50 IN LC CC | Lumineq | 3.5 | 160×80 |
| EL640.400-CB1 FRA | Lumineq | 9.1 | 640×400 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G156HTD01.0 | AUO | 15.6 | 1920×1080 |
| G185XW01 V2 | AUO | 18.5 | 1366×768 |
| HSD121MS11-A | HannStar | 12.1 | 800×600 |
| M190EG01 V3 | AUO | 19.0 | 1280×1024 |
| RX024A-03 | ROGIN | 2.4 | 480×234 |
| TX14D12VM1CBA | KOE | 5.7 | 320×240 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
