| Nama Wahi | HV070WS1-105 |
| Waitohu | HYDIS |
| Rahi | 7.0 |
| Taupānga | PAD |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HYDIS |
| panel model | HV070WS1-105 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 153.6×90 mm |
| outline | 163.6×102.9×2.67 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC) |
| response time | 50 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S4PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| BP070WSA-400 | BOE | 7.0 | 1024×600 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| HV070WS1-100 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-101 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E1 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E2 | HYDIS | 7.0 | 1024×600 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| HJ101IA-01F | Innolux | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPR1 | LG Display | 12.5 | 1366×768 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| N101BCG-L21 | Innolux | 10.1 | 1366×768 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
