| Nama Wahi | HV070WS1-101 |
| Waitohu | HYDIS |
| Rahi | 7.0 |
| Taupānga | MP4 |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HYDIS |
| panel model | HV070WS1-101 2 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 153.6×90 mm |
| outline | 163.6×102.9×2.67 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 50 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S4PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| input voltage | 3.3V (Typ.) |
| application | MP4 |
