| Nama Wahi | HV070WX2-100 |
| Waitohu | HYDIS |
| Rahi | 7.0 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HYDIS |
| panel model | HV070WX2-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 94.2×150.72 mm |
| outline | 104.32×161.67×3.75 mm |
| surface | |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S5PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 31 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| 70WVW1A | SII | 7.0 | 800×480 |
| HV070WS1-100 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-101 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E1 | HYDIS | 7.0 | 1024×600 |
| HV070WS1-1E2 | HYDIS | 7.0 | 1024×600 |
| HV070WSA-100 | BOE | 7.0 | 1024×600 |
| HV070WX2-100 | HYDIS | 7.0 | 800×1280 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| HSD100PXN1-A00-C40 | HannStar | 10.0 | 1024×768 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LP079X01-SMAV | LG Display | 7.9 | 768×1024 |
| LP125WH2-SLT1 | LG Display | 12.5 | 1366×768 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| N080ICE-GB0 Rev.A1 | Innolux | 8.0 | 800×1280 |
| VVX11F019G00 | Panasonic | 11.6 | 1920×1080 |
