N080ICE-GB0 Rev.A1

N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1
N080ICE-GB0 Rev.A1 thumb N080ICE-GB0 Rev.A1 thumb
Waitohu
Innolux
Rahi
8.0
Taupānga
PAD
Whakatau
800×1280
Te tito
LCM
Tirohanga
400
CR
800:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
MIPI
In Stock
1720
Whakatakotoranga

Nama Wahi N080ICE-GB0 Rev.A1
WaitohuInnolux
Rahi8.0
TaupāngaPAD
Whakatau800×1280
Te titoLCM
Tirohanga400
CR800:1
Nga Tae16.7M
WhakamuriWLED
AtangaMIPI
panel brandINNOLUX
panel modelN080ICE-GB0 Rev.A1
panel type a-Si TFT-LCD , LCM
panel size8.0 inch
resolution800(RGB)×1280 , WXGA
display modeAAS, Normally Black, Transmissive
active area107.64×172.224 mm
outline114.58×184.09×4.06 mm
surfaceHard coating, Antireflection
brightness400 cd/m² (Typ.)
contrast ratio800:1 (Typ.)
display colors16.7M (8-bit), CIE193160%
response time20 (Typ.)(Tr+Td)
viewing angle89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type4 stringsWLEDWithout Driver
signal interfaceMIPI (4 data lanes), 31 pins
input voltage1.8/3.3V (Typ.)(VDDI/VCI)
applicationPAD
