| Nama Wahi | LPM070W425D |
| Waitohu | JDI |
| Rahi | 7.0 |
| Taupānga | PAD |
| Whakatau | 1200×1920 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 1100:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | MIPI |
| panel brand | JDI |
| panel model | LPM070W425D |
| panel type | LTPS TFT-LCD , CELL |
| panel size | 7.0 inch |
| resolution | 1200(RGB)×1920 , WUXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 94.5×151.2 mm |
| outline | 97.3×159.4 mm |
| surface | |
| glass depth | 0.25+0.25 mm |
| transmissivity | 5.2% (Typ.)(with Polarizer) |
| contrast ratio | 1100:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Built-in ISL97692IRTZ |
| signal interface | MIPI (4 data lanes), 31 pins |
| input voltage | 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP) |
| application | PAD |
