| Nama Wahi | TV096WXM-NS0 |
| Waitohu | BOE |
| Rahi | 9.6 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | TV096WXM-NS0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.6 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | ADS, Normally Black, Transmissive |
| active area | 129×206.4 mm |
| outline | 136.7×217×4.65 mm |
| surface | Hard coating, Antireflection |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193147% |
| response time | |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S4PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
