| Nama Wahi | A080SN03 V2 |
| Waitohu | AUO |
| Rahi | 8.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 500:1 |
| Nga Tae | 16.2M |
| Whakamuri | No B/L |
| Atanga | TTL |
| panel brand | AUO |
| panel model | A080SN03 V2 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 8.0 inch |
| resolution | 800×600(RGB) , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 170.1×132.3 mm |
| surface | Antiglare, Hard coating (3H) |
| glass depth | 0.50+0.50 mm |
| transmissivity | 4.88% (Typ.)(with Polarizer) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.2M (6-bit + Dithering), CIE193150% |
| response time | 12/18 (Typ.)(Tr/Td) |
| viewing angle | 70/70/60/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | TTL (1 ch, 8-bit) + SPI, 60 pins |
| input voltage | 3.3/5/-5/14/-14V (Typ.)(VDDIO/VDPA/VDNA/VGH/VGL) |
| application | DPF |
