| Nama Wahi | A080SN01 V0 |
| Waitohu | AUO |
| Rahi | 8.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | 400:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | A080SN01 V0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141 mm |
| surface | Antiglare |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Dithering) |
| response time | 4/16 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S8PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| input voltage | 3.3/11.6/15/-6.75V (Typ.)(VCC/AVDD/VGH/VGL) |
| application | DPF |
