| Nama Wahi | HSD100PXN1-A00-C40 |
| Waitohu | HannStar |
| Rahi | 10.0 |
| Taupānga | PAD |
| Whakatau | 1024×768 |
| Te tito | Assembly |
| Tirohanga | 180 |
| CR | 600:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HannStar |
| panel model | HSD100PXN1-A00-C40 |
| panel type | a-Si TFT-LCD , Assembly |
| panel size | 10.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| active area | 202.752×152.064 mm |
| outline | 243.8×190.8×7.4 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 180 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| viewing angle | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
