| Nama Wahi | LB080WV4-TD02 |
| Waitohu | LG Display |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 600 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | LG.Philips LCD |
| panel model | LB080WV4-TD02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 176.64×99.36 mm |
| outline | 199×121 mm |
| surface | Antiglare |
| brightness | 600 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193145% |
| response time | 10/20 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| input voltage | 5.0V (Typ.) |
| application | CNS |
