| Nama Wahi | LSL080AL02-002 |
| Waitohu | Samsung |
| Rahi | 8.0 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | MIPI |
| panel brand | SAMSUNG |
| panel model | LSL080AL02-002 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 8.0 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 107.64×172.224 mm |
| outline | 112.64×181.824×0.69 mm |
| surface | Glare (Haze 0%), Hard coating |
| glass depth | 0.20+0.20 mm |
| transmissivity | 6.6% (Typ.)(with Polarizer) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | MIPI (4 data lanes), 34 pins |
| input voltage | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| application | PAD |
