| Nama Wahi | HT121WX2-211 |
| Waitohu | HYDIS |
| Rahi | 12.1 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 200 |
| CR | |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HYDIS |
| panel model | HT121WX2-211 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 261.12×163.2 mm |
| outline | 276.8×180 mm |
| surface | |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | |
| display colors | 262K (6-bit) |
| response time | |
| viewing angle | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit) |
| input voltage | 3.3V (Typ.) |
| application | PAD |
| A121EW02 V0 | AUO | 12.1 | 1280×800 |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| HSD121PS11-A | HannStar | 12.1 | 800×600 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| LQ121S1LG73 | SHARP | 12.1 | 800×600 |
| LQ121S1LG81 | SHARP | 12.1 | 800×600 |
| LT121DEVQB00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EX1S | TOSHIBA | 12.1 | 1280×768 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| B080UAN01.4 | AUO | 8.0 | 1200×1920 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTN101AL03-001 | Samsung | 10.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
