| Nama Wahi | A121EW02 V0 |
| Waitohu | AUO |
| Rahi | 12.1 |
| Taupānga | GM |
| Whakatau | 1280×800 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 350:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | A121EW02 V0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 261.12×163.2 mm |
| outline | 278.2×184×14.1 mm |
| surface | |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 12/18 (Typ.)(Tr/Td) |
| viewing angle | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | GM |
