| Nama Wahi | BA121S01-100 |
| Waitohu | BOE |
| Rahi | 12.1 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | BA121S01-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 246×184.5 mm |
| outline | 279×209×9.3 mm |
| surface | |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193155% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/65/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| 121SVA0501-2 | SANYO | 12.1 | 800×600 |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| BA121S01-100 | BOE | 12.1 | 800×600 |
| HV121WX6-110 | HYDIS | 12.1 | 1280×800 |
| LB121S03-TL02 | LG Display | 12.1 | 800×600 |
| LQ121S1DG31 | SHARP | 12.1 | 800×600 |
| LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
| LTM12C283 | TOSHIBA | 12.1 | 800×600 |
| TM121SDS01 | Tianma | 12.1 | 800×600 |
| TX31D37VM0CAA | KOE | 12.1 | 800×600 |
| AA121SN03 | Mitsubishi | 12.1 | 800×600 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| BA104S01-100 | BOE | 10.4 | 800×600 |
| HSD121MS11-A | HannStar | 12.1 | 800×600 |
| LM24P20 | SHARP | 5.7 | 240×128 |
| LT104AC36000 | TOSHIBA | 10.4 | 1024×768 |
| LTM121SI-T01 | Samsung | 12.1 | 800×600 |
| PD057VT3 | E Ink | 5.7 | 640×480 |
| TX17D200VM0BAA | KOE | 6.5 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
