| Nama Wahi | TX23D85VM0BAA |
| Waitohu | KOE |
| Rahi | 9.0 |
| Taupānga | IA |
| Whakatau | 1280×768 |
| Te tito | LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | HITACHI |
| panel model | TX23D85VM0BAA |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.0 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 193.92×116.352 mm |
| surface | |
| brightness | |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | |
| viewing angle | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit) |
| application | IA |
