| Nama Wahi | ED090NA-01D |
| Waitohu | Innolux |
| Rahi | 9.0 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | Assembly |
| Tirohanga | 200 |
| CR | 700:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | CHIMEI INNOLUX |
| panel model | ED090NA-01D |
| panel type | a-Si TFT-LCD , Assembly |
| panel size | 9.0 inch |
| resolution | 1280(RGB)×800 , WXGA |
| active area | 193.92×121.2 mm |
| outline | 235.12×156.4×7.84 mm |
| surface | Hard coating (7H) |
| brightness | 200 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193170% |
| viewing angle | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 6/8-bit), 51 pins |
| input voltage | 3.3/11.0/20.0/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL) |
| application | PAD |
