AUO B101UAN07.2 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


B101UAN07.2

B101UAN07.2
B101UAN07.2
B101UAN07.2 thumb B101UAN07.2 thumb
Waitohu
AUO
Rahi
10.1
Taupānga
PAD
Whakatau
1200×1920
Te tito
LCM
Tirohanga
400
CR
1000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
MIPI
In Stock
19103
Whakatakotoranga

Nama Wahi B101UAN07.2
WaitohuAUO
Rahi10.1
TaupāngaPAD
Whakatau1200×1920
Te titoLCM
Tirohanga400
CR1000:1
Nga Tae16.7M
WhakamuriWLED
AtangaMIPI
panel brandAUO
panel modelB101UAN07.2
panel type a-Si TFT-LCD , LCM
panel size10.1 inch
resolution1200(RGB)×1920 , WUXGA
display modeAHVA, Normally Black, Transmissive
active area135.36×216.576 mm
outline143×227.93×4.3 mm
surfaceGlare (Haze 0%), Hard coating
brightness400 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (8-bit), CIE193171%
response time25 (Typ.)(Tr+Td)
viewing angle85/85/85/85 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type8S4PWLEDWithout Driver
signal interfaceMIPI (4 data lanes), 45 pins
input voltage3.3V (Typ.)
applicationPAD
