| Nama Wahi | A090VW01 V3 |
| Waitohu | AUO |
| Rahi | 9.0 |
| Taupānga | DPF |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | A090VW01 V3 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 9.0 inch |
| resolution | 800×480(RGB) , WVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 199.2×110.16 mm |
| outline | 211.7×125 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193148% |
| response time | 4/12 (Typ.)(Tr/Td) |
| viewing angle | 70/70/55/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S8PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit) + SPI, 68 pins |
| input voltage | 3.3/5.5/-5.5/10/-13V (Typ.)(VCC/VDPA/VDNA/VGH/VGL) |
| application | DPF |
