| Nama Wahi | LQ10D42 |
| Waitohu | SHARP |
| Rahi | 10.4 |
| Taupānga | IA |
| Whakatau | 640×480 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 100:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | SHARP |
| panel model | LQ10D42 3 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.4 inch |
| resolution | 640(RGB)×480 , VGA |
| display mode | TN, Normally White, Transmissive |
| active area | 211.2×158.4 mm |
| outline | 265×195×11.5 mm |
| surface | Antiglare (Haze 28%), Hard coating (2H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 100:1 (Min.) |
| display colors | 262K (6-bit) |
| response time | 30/50 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/50 (Min.)(CR＞5)(L/R/U/D) |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| input voltage | 5.0V (Typ.)(VCC) |
| application | IA |
