| Nama Wahi | LQ170E1LG21 |
| Waitohu | SHARP |
| Rahi | 17.0 |
| Taupānga | GM |
| Whakatau | 1280×1024 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 1000:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SHARP |
| panel model | LQ170E1LG21 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×1024 , SXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 337.92×270.336 mm |
| outline | 358.5×296.5×13.4 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193176% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| input voltage | 5.0V (Typ.) |
| application | GM |
| B170PW06 V3 | AUO | 17.0 | 1440×900 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LQ170E1LG11 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LQ170K1LW02 | SHARP | 17.0 | 1280×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTN170BT09-001 | Samsung | 17.0 | 1440×900 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| A081VW01 V0 | AUO | 8.1 | 800×300 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
| G220SVN01.0 | AUO | 22.0 | 1680×1050 |
| G230HAN01.1 | AUO | 23.0 | 1920×1080 |
| LQ110Y1LG12 | SHARP | 11.0 | 800×480 |
| LQ150X1LG96 | SHARP | 15.0 | 1024×768 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LQ190E1LC06 | SHARP | 19.0 | 1280×1024 |
| LV057JC111 | Innolux | 5.7 | 640×480 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
