| Nama Wahi | LQ170K1LW02 |
| Waitohu | SHARP |
| Rahi | 17.0 |
| Taupānga | GM |
| Whakatau | 1280×768 |
| Te tito | LCM |
| Tirohanga | 300 |
| CR | 600:1 |
| Nga Tae | 16.2M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SHARP |
| panel model | LQ170K1LW02 3 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | P-MVA, Normally Black, Transmissive |
| active area | 369.6×221.76 mm |
| outline | 413.8×259×16 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 300 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC) |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| input voltage | 5.0V (Typ.) |
| application | GM |
