| Nama Wahi | LQ170M1LA4B |
| Waitohu | SHARP |
| Rahi | 17.0 |
| Taupānga | NBPC |
| Whakatau | 1920×1200 |
| Te tito | LCM |
| Tirohanga | 340 |
| CR | 450:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SHARP |
| panel model | LQ170M1LA4B 1 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1920(RGB)×1200 , WUXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 365.76×228.6 mm |
| outline | 382.2×248×7 mm |
| shape style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| surface | Glare (Haze 0%), Hard coating (2H), Antireflection |
| brightness | 340 cd/m² (Typ.) |
| contrast ratio | 450:1 (Typ.) |
| display colors | 262K (6-bit), CIE193172% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| rohs: | |
| application | NBPC |
