| Nama Wahi | ZE090NA-01B |
| Waitohu | Innolux |
| Rahi | 9.0 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 700:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | LVDS |
| panel brand | CHIMEI INNOLUX |
| panel model | ZE090NA-01B |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 9.0 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 193.92×121.2 mm |
| outline | 206.76×135.06×1.43 mm |
| surface | |
| glass depth | 0.50+0.50 mm |
| transmissivity | 3.39% (Typ.)(with Polarizer) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193170% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/50/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | LVDS (1 ch, 6/8-bit), 40 pins |
| input voltage | 3.3/11.0/20.0/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| application | PAD |
