| Nama Wahi | BA104S01-100 |
| Waitohu | BOE |
| Rahi | 10.4 |
| Taupānga | IA |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | BA104S01-100 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.4 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 211.2×158.4 mm |
| outline | 236×176.9×5.9 mm |
| surface | Clear |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 6S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | IA |
| BA104S01-100 | BOE | 10.4 | 800×600 |
| BA104S01-200 | BOE | 10.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| LB104S01-TL01 | LG Display | 10.4 | 800×600 |
| LB104S04-TL01 | LG Display | 10.4 | 800×600 |
| LQ10D341 | SHARP | 10.4 | 640×480 |
| LTA104A261F | TOSHIBA | 10.4 | 640×480 |
| LTN104S1-L01 | Samsung | 10.4 | 800×600 |
| NL6448BC33-64E | NLT | 10.4 | 640×480 |
| NL8060BC26-13 | NLT | 10.4 | 800×600 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| DMF-50773NB-FW | Kyocera | 5.4 | 240×128 |
| DMF-50773NF-FW | Kyocera | 5.4 | 240×128 |
| DMF50773NF-SLY | Kyocera | 5.4 | 240×128 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| P50CD4 | E Ink | 5.0 | 320×234 |
| TX23D86VM0BAA | KOE | 9.0 | 1280×768 |
| TX26D01VM1CAA | KOE | 10.4 | 640×480 |
| TX26D12VM0AAA | KOE | 10.4 | 800×600 |
