| Nama Wahi | A080XN01 V1 |
| Waitohu | AUO |
| Rahi | 8.0 |
| Taupānga | GM |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 600:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | A080XN01 V1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162.048×121.536 mm |
| outline | 183×141.91 mm |
| surface | Antiglare, Hard coating (2H) |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193145% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 55/55/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S10PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| input voltage | 3.3/5.3/-5.3V (Typ.)(VDDIO/VDPA/VDNA) |
| application | GM |
