| Nama Wahi | LD080WX2-SMN1 |
| Waitohu | LG Display |
| Rahi | 8.0 |
| Taupānga | PAD |
| Whakatau | 800×1280 |
| Te tito | LCM |
| Tirohanga | 330 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | LG Display |
| panel model | LD080WX2-SMN1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×1280 , WXGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 107.64×172.224 mm |
| outline | 114.6×184.55×4.25 mm |
| surface | Hard coating |
| brightness | 330 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S3PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| input voltage | 1.8/5.2/-5.2V (Typ.)(VDDI/AVDD/AVEE) |
| application | PAD |
