| Nama Wahi | BP080WX7-100 |
| Waitohu | BOE |
| Rahi | 8.0 |
| Taupānga | PAD |
| Whakatau | 1280×800 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | No B/L |
| Atanga | MIPI |
| panel brand | BOE |
| panel model | BP080WX7-100 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 8.0 inch |
| resolution | 1280(RGB)×800 , WXGA |
| display mode | HFFS, Normally Black, Transmissive |
| active area | 172.224×107.64 mm |
| outline | 179.6×116.9×0.793 mm |
| surface | Hard coating (3H) |
| glass depth | 0.25+0.25 mm |
| contrast ratio | 900:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193155% |
| response time | 24 (Typ.)(Tr+Td) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | MIPI (4 data lanes), 31 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
