| Nama Wahi | LTE700WQ-F05 |
| Waitohu | Samsung |
| Rahi | 7.0 |
| Taupānga | DPF |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LTE700WQ-F05 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480×234(RGB) |
| display mode | TN, Normally White, TMR |
| active area | 154.08×86.58 mm |
| outline | 166×100×7.2 mm |
| surface | |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 13/17 (Typ.)(Tr/Td) |
| viewing angle | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| input voltage | 2.5/3.3V (Typ.)(VDD) |
| application | DPF |
