| Nama Wahi | AT080TN42 |
| Waitohu | Innolux |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | INNOLUX |
| panel model | AT080TN42 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| application | CNS |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.2 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT080TN42 | Innolux | 8.0 | 800×600 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AT080TN64 | Innolux | 8.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| DLC0700EZG-2 | Other | 7.0 | 800×480 |
| HSD040I3N1-B00 | HannStar | 4.0 | 320×240 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| L5F30442T15 | Epson | 6.5 | 800×480 |
| LA058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LA080WV2-TD01 | LG Display | 8.0 | 800×480 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| YX050800480WTIPS | 5.0 | 800×480 |
