Innolux AT080TN42 V.1 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


AT080TN42 V.1

AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1
AT080TN42 V.1 thumb AT080TN42 V.1 thumb AT080TN42 V.1 thumb
Waitohu
Innolux
Rahi
8.0
Taupānga
CNS
Whakatau
800×600
Te tito
LCM
Tirohanga
250
CR
500:1
Nga Tae
262K
Whakamuri
WLED
Atanga
TTL
In Stock
493
Whakatakotoranga

Nama Wahi AT080TN42 V.1
WaitohuInnolux
Rahi8.0
TaupāngaCNS
Whakatau800×600
Te titoLCM
Tirohanga250
CR500:1
Nga Tae262K
WhakamuriWLED
AtangaTTL
panel brandINNOLUX
panel modelAT080TN42 V.1
panel type a-Si TFT-LCD , LCM
panel size8.0 inch
resolution800(RGB)×600 , SVGA
display modeTN, Normally White, Transmissive
active area162×121.5 mm
outline183×141 mm
surfaceAntiglare
brightness250 cd/m² (Typ.)
contrast ratio500:1 (Typ.)
display colors262K (6-bit)
response time10/15 (Typ.)(Tr/Td)
viewing angle70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
lamp type3S9PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6-bit), 60 pins
input voltage3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
applicationCNS
