AT080TN03 V.7

AT080TN03 V.7
AT080TN03 V.7
AT080TN03 V.7
AT080TN03 V.7 thumb AT080TN03 V.7 thumb AT080TN03 V.7 thumb
Waitohu
Innolux
Rahi
8.0
Taupānga
DPF
Whakatau
800×480
Te tito
LCM
Tirohanga
300
CR
300:1
Nga Tae
262K
Whakamuri
WLED
Atanga
TTL
In Stock
9409
Whakatakotoranga

Nama Wahi AT080TN03 V.7
WaitohuInnolux
Rahi8.0
TaupāngaDPF
Whakatau800×480
Te titoLCM
Tirohanga300
CR300:1
Nga Tae262K
WhakamuriWLED
AtangaTTL
panel brandINNOLUX
panel modelAT080TN03 V.7
panel type a-Si TFT-LCD , LCM
panel size8.0 inch
resolution800(RGB)×480 , WVGA
display modeTN, Normally White, Transmissive
active area176.64×99.36 mm
outline192.8×116.9×6.7 mm
surfaceAntiglare
brightness300 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colors262K (6-bit)
response time15/20 (Typ.)(Tr/Td)
viewing angle65/65/45/65 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type3S9PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6-bit), 60 pins
input voltage3.3/10.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
applicationDPF
