| Nama Wahi | EK08009-70235 |
| Waitohu | Other |
| Rahi | 8.0 |
| Taupānga | DPF |
| Whakatau | 800×600 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | No Brand |
| panel model | EK08009-70235 4 Compatible model |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×600 , SVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 162×121.5 mm |
| outline | 183×141 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 10/15 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 3S11PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| input voltage | 3.3/10.4V (Typ.)(VCC/AVDD) |
| rohs: | |
| application | DPF |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| B080UAN01.2 | AUO | 8.0 | 1200×1920 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| C080VW05 V0 | AUO | 8.0 | 800×480 |
| EK08009-70235 | Other | 8.0 | 800×600 |
| HJ080IA-01B | Innolux | 8.0 | 1024×768 |
| LM64P122 | SHARP | 8.0 | 640×480 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| PW080XU1 | E Ink | 8.0 | 480×220 |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT080TN01 | Innolux | 8.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| HSD090ICW1-A00 | HannStar | 9.0 | 640×234 |
| HSD100IFW1-C01 | HannStar | 10.1 | 1024×600 |
| HSD100IXN1-A00 | HannStar | 10.0 | 1024×768 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
