| Nama Wahi | C080VW04 V0 |
| Waitohu | AUO |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | AUO |
| panel model | C080VW04 V0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | AMVA, Normally Black, Transmissive |
| active area | 174×104.4 mm |
| outline | 188.5×123×11.05 mm |
| surface | Antiglare, Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| response time | 35 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S3PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 64 pins |
| input voltage | 3.3/13/15/-10V (Typ.)(VDDIO/AVDD/VGH/VGL) |
| application | CNS |
