| Nama Wahi | TJ123NP01BA |
| Waitohu | Innolux |
| Rahi | 12.3 |
| Taupānga | CNS |
| Whakatau | 1280×480 |
| Te tito | LCM |
| Tirohanga | 600 |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL/RSDS |
| panel brand | CHIMEI INNOLUX |
| panel model | TJ123NP01BA |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 12.3 inch |
| resolution | 1280(RGB)×480 , DVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 291.84×109.44 mm |
| outline | 333.8×134.6×44.1 mm |
| surface | Antiglare |
| brightness | 600 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) |
| display colors | 262K (6-bit), CIE193155% |
| response time | 5/15 (Typ.)(Tr/Td) |
| viewing angle | 60/60/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 stringsWLEDWithout Driver |
| signal interface | TTL/RSDS (1 ch, 6-bit), 50 pins |
| input voltage | 3.3/6.0/-6.0V (Typ.)(VCC/VDDP/VDDN) |
| application | CNS |
