| Nama Wahi | PW080XU1 |
| Waitohu | E Ink |
| Rahi | 8.0 |
| Taupānga | CNS |
| Whakatau | 480×220 |
| Te tito | LCM |
| Tirohanga | 350 |
| CR | 350:1 |
| Nga Tae | |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | PVI |
| panel model | PW080XU1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.0 inch |
| resolution | 480(RGB)×220 |
| display mode | TN, Normally White, Transmissive |
| active area | 180.72×94.27 mm |
| outline | 193×108.3×7 mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| input voltage | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VCCG/AVDD/VGH/VEE) |
| application | CNS |
