| Nama Wahi | LB070WV3-SD02 |
| Waitohu | LG Display |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 800×480 |
| Te tito | LCM |
| Tirohanga | 470 |
| CR | 900:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | LG Display |
| panel model | LB070WV3-SD02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 800(RGB)×480 , WVGA |
| display mode | IPS, Normally Black, Transmissive |
| active area | 152.4×91.44 mm |
| outline | 170×109.6×29.4 mm |
| surface | Antiglare, Antireflection |
| brightness | 470 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 262K (6-bit), CIE193163% |
| response time | 15/14 (Typ.)(Tr/Td) |
| viewing angle | 70/70/30/30 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 5S3PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| input voltage | 3.3V (Typ.) |
| application | CNS |
