| Nama Wahi | C070FW02 V2 |
| Waitohu | AUO |
| Rahi | 7.0 |
| Taupānga | CNS |
| Whakatau | 480×234 |
| Te tito | LCM |
| Tirohanga | 410 |
| CR | 300:1 |
| Nga Tae | |
| Whakamuri | CCFL |
| Atanga | Analog |
| panel brand | AUO |
| panel model | C070FW02 V2 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 480(RGB)×234 |
| display mode | TN, Normally White, Transmissive |
| active area | 154.08×86.58 mm |
| outline | 164.9×100 mm |
| surface | Antiglare (Haze 25%) |
| brightness | 410 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | |
| response time | 12/18 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| input voltage | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| application | CNS |
| 70WVW2A | SII | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
| AT070TN82 V.1 | Innolux | 7.0 | 800×480 |
| C070FW01 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PM070WX1 | E Ink | 7.0 | 800×480 |
| AV128HDM-NW0 | BOE | 12.8 | 1280×720 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| G080Y1-T01 | Innolux | 8.0 | 800×480 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LB040Q02-TD01 | LG Display | 4.0 | 320×240 |
| LQ070Y5DG36 | SHARP | 7.0 | 800×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
