Innolux AT070TN82 V.1 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


AT070TN82 V.1

AT070TN82 V.1
AT070TN82 V.1
AT070TN82 V.1
AT070TN82 V.1 thumb AT070TN82 V.1 thumb AT070TN82 V.1 thumb
Waitohu
Innolux
Rahi
7.0
Taupānga
MP4
Whakatau
800×480
Te tito
LCM
Tirohanga
250
CR
500:1
Nga Tae
262K
Whakamuri
WLED
Atanga
TTL
In Stock
500
Whakatakotoranga

Nama Wahi AT070TN82 V.1
WaitohuInnolux
Rahi7.0
TaupāngaMP4
Whakatau800×480
Te titoLCM
Tirohanga250
CR500:1
Nga Tae262K
WhakamuriWLED
AtangaTTL
panel brandINNOLUX
panel modelAT070TN82 V.1
panel type a-Si TFT-LCD , LCM
panel size7.0 inch
resolution800(RGB)×480 , WVGA
display modeTN, Normally White, Transmissive
active area152.4×91.44 mm
outline165×104×6.3 mm
surfaceAntiglare
brightness250 cd/m² (Typ.)
contrast ratio500:1 (Typ.)
display colors262K (6-bit)
response time10/15 (Typ.)(Tr/Td)
viewing angle70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
lamp type3S9PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6-bit), 60 pins
input voltage3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
applicationMP4
Tauira Whanau
AT070TN07 V.A Innolux 7.0 480×234
AT070TN07 V.D Innolux 7.0 480×234
AT070TN82 Innolux 7.0 800×480
AT070TN83 V.1 Innolux 7.0 800×480
AT070TN83 V.3 Innolux 7.0 800×480
AT070TN84 V.1 Innolux 7.0 800×480
AT070TN90 V.1 Innolux 7.0 800×480
AT070TN92 V.1 Innolux 7.0 800×480
AT070TN93 V.2 Innolux 7.0 800×480
AT070TN94 Innolux 7.0 800×480
Hua wera
AT070TN92 V.3 Innolux 7.0 800×480
BA070WS1-401 BOE 7.0 1024×600
BA070WS1-402 BOE 7.0 1024×600
CLAA070NC0BCT CPT 7.0 1024×600
HV070WS1-100 HYDIS 7.0 1024×600
LMS700KF01-001 Samsung 7.0 800×480
LTP700WV-F01 Samsung 7.0 800×480
Q070LRE-L81 Innolux 7.0 1024×600
TM070DDH08 Tianma 7.0 1024×600
TM080XPH01 Tianma 8.0 1280×768
