| Nama Wahi | TM080XPH01 |
| Waitohu | Tianma |
| Rahi | 8.0 |
| Taupānga | MP4 |
| Whakatau | 1280×768 |
| Te tito | CELL |
| Tirohanga | 0 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | No B/L |
| Atanga | Mini LVDS |
| panel brand | TIANMA |
| panel model | TM080XPH01 |
| panel type | a-Si TFT-LCD , CELL |
| panel size | 8.0 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 173.76×104.256 mm |
| outline | 181×112.8×3.05 mm |
| surface | |
| glass depth | 0.50+0.50 mm |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit), CIE193150% |
| response time | 25/25 (Typ.)(Tr/Td) |
| viewing angle | 70/70/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| signal interface | Mini LVDS, 40 pins |
| input voltage | 3.3/12.5/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| application | MP4 |
