Innolux AT070TN92 V.3 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


AT070TN92 V.3

AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3
AT070TN92 V.3 thumb AT070TN92 V.3 thumb AT070TN92 V.3 thumb
Waitohu
Innolux
Rahi
7.0
Taupānga
MP4
Whakatau
800×480
Te tito
LCM
Tirohanga
250
CR
500:1
Nga Tae
262K/16.7M
Whakamuri
WLED
Atanga
TTL
In Stock
6457
Whakatakotoranga

Nama Wahi AT070TN92 V.3
WaitohuInnolux
Rahi7.0
TaupāngaMP4
Whakatau800×480
Te titoLCM
Tirohanga250
CR500:1
Nga Tae262K/16.7M
WhakamuriWLED
AtangaTTL
panel brandCHIMEI INNOLUX
panel modelAT070TN92 V.3
panel type a-Si TFT-LCD , LCM
panel size7.0 inch
resolution800(RGB)×480 , WVGA
display modeTN, Normally White, Transmissive
active area154.08×85.92 mm
outline164.9×100×3.65 mm
surfaceAntiglare
brightness250 cd/m² (Typ.)
contrast ratio500:1 (Typ.)
display colors262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150%
response time10/15 (Typ.)(Tr/Td)
viewing angle70/70/50/70 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type3S9PWLEDWithout Driver
signal interfaceParallel RGB (1 ch, 6/8-bit), 50 pins
input voltage3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL)
applicationMP4
