Innolux AT070TN07 V.A Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


AT070TN07 V.A

AT070TN07 V.A
AT070TN07 V.A
AT070TN07 V.A
AT070TN07 V.A thumb AT070TN07 V.A thumb AT070TN07 V.A thumb
Waitohu
Innolux
Rahi
7.0
Taupānga
VDP
Whakatau
480×234
Te tito
LCM
Tirohanga
200
CR
300:1
Nga Tae
Full color
Whakamuri
WLED
Atanga
Analog
In Stock
802
Whakatakotoranga

Nama Wahi AT070TN07 V.A
WaitohuInnolux
Rahi7.0
TaupāngaVDP
Whakatau480×234
Te titoLCM
Tirohanga200
CR300:1
Nga TaeFull color
WhakamuriWLED
AtangaAnalog
panel brandINNOLUX
panel modelAT070TN07 V.A
panel type a-Si TFT-LCD , LCM
panel size7.0 inch
resolution480(RGB)×234
display modeTN, Normally White, Transmissive
active area154.08×86.58 mm
outline164.9×100 mm
surfaceAntiglare
brightness200 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colorsFull color
response time15/20 (Typ.)(Tr/Td)
viewing angle60/60/40/60 (Typ.)(CR≥10)(L/R/U/D)
lamp type2S9PWLEDWithout Driver
signal interfaceTFT Specific Analog RGB, 26 pins
input voltage(3.3/5.0)/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
applicationVDP
